ENVISION

Compact | Versatile | Portable
The ENVISION Micro-ATX case, known as “Full Metal Jacket,” is a rugged, industrial-grade computer chassis built for users who demand durability, versatility and portability in a compact design. Made entirely from premium metal, this case provides exceptional protection and a minimalist design that distinguishes it from typical cases, makes it a perfect chassis for high performance setup without sacrificing strength and style.

Specifications

Key Specs

Motherboard Support：M-ATX, ITX
Case Material：Grade-A 0.8mm SPCC
Colours Available : Black, White

Compatibility & Clearance

Max GPU Clearance：310mm
PCIE Expansion Slot：4
Max CPU Cooler Clearance：135mm
PSU Form Factor : ATX, SFX (bracket included)

Fan Support

Top : 2 x 90mm or 2 x 80mm
Bottom : 2 x 120mm or 3 x 90mm
Rear : 1 x 90mm or 1 x 80mm

*Pre-installed 3x 90mm Fan

I/O

1 x USB 3.0 (Type-C)
2 x USB 3.0 (Type-A)
1 x USB 2.0 (Type-A)
1 x HD Audio

Dimensions

Height：310mm
Width：165mm
Depth：350mm

Drive Bays

2 x 2.5" + 1 x 3.5"
or
3 x 2.5"

Radiator Support

Side : 240mm
* Requires using SFX PSU (bracket included) and removal of rear 90mm fan.

Additional Information

Packing size: 335 x 203 x 400mm
Net weight : 2.8kg
Gross weight : 3.3kg
